APACER isn't new to the RGB scene when it comes to memory but their previous offering has been a bit on the flamboyant side of stylings.  Featuring wild cats and odd cuts on the diffusers they may have kept quite a few folks from being too interested, but their NOX lineup seems to be remedying that image.  APACER NOX RGB DDR4 uses unique ultra-wide angle RGB lighting effects featuring exquisitely carved lighting bar with natural, flowing RGB colors displayed in full view. NOX RGB DDR4 is certified by the software of major motherboard manufacturers such as ASUS AURA Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, and ASRock Polychrome Sync. The RGB can be controlled to match your other RGB parts in your PC.

First Look - Unbox and Closer Look

The APACER NOX RGB Kit comes in a simple package, not as ornate as some come shipped in, but all the pertinent information is available on the packaging and there are dual-window openings on the back revealing the memory specification stickers on the heatsink of each stick.  The memory has heat spreaders applied to both sides via a thermal adhesive, which is a bit of a downer since most kits in this range are fully surrounded and attached with some more secure methods, like screws.  But the overall design is rather understated with the exception of the large diffuser on top that adorns the NOX logo.

Related StoryJason R. Wilson
Could AMD’s RDNA 3 Navi 31 GPU For Radeon RX 7900 XT Offer An Effective Bandwidth of Over 6 TB/s?
p1030089
p1030090
p1030082
p1030083
p1030084
p1030085
p1030086
p1030087
p1030088
p1030081

That top diffuser does a spectacular job diffusing the RGB LEDs and results in a very soft, yet bright, display of colors.  The fact that the color pattern can be seen from all angles explains what they meant by 'Ultra-wide Angle'. Software control functioned normally as one would expect when using the software on various motherboards, I tested them with MSI, Gigabyte, and Asus and none of the vendor's software had issues controlling the lighting.

p1030027-2
p1030028
p1030029

APACER NOX Lineup

NOX RGB DDR4 has passed compatibility certifications of most mainstream motherboard manufacturers, ensuring that the product can operate stably on the motherboards listed on QVL. In order to cater to the different needs of all gamers, single-channel and dual-channel packages are provided from 4GB to 32GB, as well as four different speed range options from the 2400 MHz 1.2 V of 16-16-16-36 to the 3200 MHz 1.35 V of 16-18-18-38.  While the ICs are stamped with APACER's logo and information, Thaiphoon Burner returns these as Samsung B-Die ICs which explains their excellent compatibility on even my 1st Gen Ryzen parts when testing.


Apacer NOX Lineup

 NOX RGB DDR4 Gaming Memory Module
Frequency/Capacity/Voltage/Cas Latency3200MHz/8GB、16GB、32GB/1.35V/16-18-18-38
3000MHz/8GB、16GB、32GB/1.35V/16-18-18-38
2666MHz/4GB、8GB、16GB、32GB/1.2V/16-18-18-36
2400MHz/4GB、8GB、16GB、32GB/1.2V/16-16-16-36
Memory Architecturex8 FBGA DRAM chip
Intel XMP 2.0Yes
PIN288-pin
CertificateRoHS, CE, FCC, RCM, VCCI, JEDEC
PackageSingle Channel Package
Dual Channel package
WarrantyLimited lifetime warranty

Testing Setup

Much like the first time I published a review for storage I have access to limited hardware and had to develop a test suite for myself to use.  Because of that the testing is still growing and open to suggestions by the readers.  Right now we have a mix of Synthetic and Gaming benchmarks as I focus primarily on the PC Gaming angle with almost all hardware.  Something I wanted to explore as we go through the results is more than just the memory's XMP Profile performance as sometimes people run into issues running memory at it's maximum capacity, therefore I conducted a set of tests using the XMP Profile for rated speeds and timings, but then adjusted the frequency to see how the memory kits all performed at lower frequencies (and higher than XMP in the case of the Corsair Vengeance LPX kit).  Hopefully, that'll give readers a better idea of where the APACER NOX memory sits overall in terms of performance.

Test System

ComponentsZ370
CPUIntel Core i9-9900k @ 5GHz
Memory APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14
MotherboardEVGA Z370 Classified K
StorageKingston KC2000 1TB NVMe SSD
PSUCooler Master V1200 Platinum
Windows Version1903 with latest security patches

APACER NOX 32GB DDR4 3200 Performance

Aida 64 Bandwidth

Using Aida 64 we are able to get a good idea of the overall bandwidth from the memory kits in Read, Write, and Copy performance.  I separated them out into their own charts per each measurement so they would be easier to read and digest.  A great aspect of this benchmark is that it is readily available to everyone to try out and see where your system's performance lands for a point of comparison.

Related StoryJason R. Wilson
Seagate 30 TB+ HAMR HDDs To Ship By Mid-2023
Aida 64 Read MB/s (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
9000
18000
27000
36000
45000
54000
0
9000
18000
27000
36000
45000
54000
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14



Aida 64 Write MB/s (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
9000
18000
27000
36000
45000
54000
0
9000
18000
27000
36000
45000
54000
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14



Aida 64 Copy MB/s (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
9000
18000
27000
36000
45000
54000
0
9000
18000
27000
36000
45000
54000
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14

Aida 64 Latency

Latency is the name of the game in this benchmark.  The lower the latency the faster the response from the memory.

Aida 64 Latency (Lower is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
20
40
60
80
100
120
0
20
40
60
80
100
120
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14

ROG RealBench Image Editing

The ROG RealBench suite is a rather useful tool for measuring performance as it's built entirely out of open source applications that people use.  For this test, we took the results from the ROG RealBench Image Editing benchmark that uses GIMP to measure performance while loading and applying many changes to photos.  Needless to say, the results point out not much reason to be concerned with what memory you're using so long as you have enough. A great aspect of this benchmark is that it is readily available to everyone to try out and see where your system's performance lands for a point of comparison.

ROG RealBench Image Editing Score (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
50
100
150
200
250
300
0
50
100
150
200
250
300
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14

WinRar

WinRar's benchmark takes a measurement of the system's capacity for file compression and translates that to KB/s showing that it really favors overall speed for the highest output. A great aspect of this benchmark is that it is readily available to everyone to try out and see where your system's performance lands for a point of comparison.

WinRar Benchmark KB/s (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
5000
10000
15000
20000
25000
30000
0
5000
10000
15000
20000
25000
30000
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14v

Rainbow 6 Siege

Rainbow 6 Siege is a highly competitive multiplayer shooter that has shown itself to be fairly CPU intensive, and memory performance is one aspect that can really help boost speeds in games that are CPU constrained.  This game proves this to be the case as well showing that there can exist up to and exceeding a 40FPS margin based on the memory speed. This was tested at 1080p Ultra Preset paired with an RTX 2080 Ti

Rainbow 6 Siege 1080p Ultra AVG FPS (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
70
140
210
280
350
420
0
70
140
210
280
350
420
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14

Far Cry New Dawn

Far Cry New Dawn may not be the same kind of competitive multiplayer game as Rainbow 6, but it is still al title that is known to put the hurt on the CPU so it should also share a very similar outcome.  While the performance delta of just over 25FPS isn't as staggering, it's still a big enough gap for people to really consider faster memory when using these higher-performing CPUs. This was tested at 1080p Ultra Preset paired with an RTX 2080 Ti

Far Cry New Dawn 1080p Ultra AVG FPS (higher is better)
DDR4 2133
DDR4 2400
DDR4 2933
XMP PROFILE
0
40
80
120
160
200
240
0
40
80
120
160
200
240
APACER VOX RGB DDR4 3200 CL16
G.Skill Flare X DDR4 3200 CL14
G.Skill Trident Z DDR4 3200 CL16
Geil EVO X DDR3200 CL 16
Corsair Vengeance LPX DDR4 2400 CL14

Conclusion

All in all the APACER NOX 32GB DDR4 3200 is a great performer and offers excellent compatibility across all systems that were tested for stability but at an MSRP of $279.99 they outside of being priced competitively.  That said, if you find them at a similar price to competing kits of memory you'll find a very valid option.  The NOX kit of memory does everything it sets out to do, it looks good, works great, integrates seamlessly into the RGB ecosystem of the motherboards I tried it on.  It had no issues running at the XMP profile on any of the systems I tried it in, and that includes a 1st gen Ryzen 1600x, 1700, and 1800X on a B350 motherboard.  Overclocking seemed very limited as I only had success with either dropping the timings to DDR4 3200 14-14-14-38 at 1.35v or was able to increase it at stock timings to 3433 and maintain 1.35v, anything more required voltage to be increased substantially. The APACER NOX 32GB DDR4 3200 is a great kit of memory that is only marred by a high MSRP, but if you find it a comparable price however and it should be on your list of considerations.

7.3
Wccftech Rating

The APACER NOX 32GB DDR4 3200 is a great kit of memory that is only marred by a high MSRP, but if you find it a comparable price however and it should be on your list of considerations.

Pros
  • Lifetime Warranty
  • Aesthetics work with wany motherboards
  • Lighting control compatible with a wide range of software
  • 32GB should fill the needs of almost all users with the exception of the heaviest power users.
  • Intel XMP Compatibility can make set up a breeze on Intel Systems
  • Ryzen compatibility even with 1st Gen
Cons
  • Too Expensive
  • Heatsinks less secure than desired
  • Timings a bit loose for the ICs used.
