want to use PTCL DSL on my own modem...

[BuNkLy]

Hi guys.....

2day i finally got my PTCL DSL connection on my ONU. my MSN signs out after every 15 mins or so.....this is not happeneing when i use the dialup so i thought mayb changin the modem helps

so i was wondering if theres any way i can use my own modem (Aztech) with PTCL DSL.....cz for sum reason im unable to. they gave me Shire modem btw.

the Internet light on the Aztech modem stays red

any help appreciated.

[luv2xlr8]

throw it in trash and see if your area has worldcall !!

[ScArFaCe]

Originally Posted by BuNkLy

Hi guys.....

2day i finally got my PTCL DSL connection on my ONU. my MSN signs out after every 15 mins or so.....this is not happeneing when i use the dialup so i thought mayb changin the modem helps

so i was wondering if theres any way i can use my own modem (Aztech) with PTCL DSL.....cz for sum reason im unable to. they gave me Shire modem btw.

the Internet light on the Aztech modem stays red

any help appreciated.

try callin CS and let them knw u wanna use yr own modem ... though its wierd abt msn prob ... my msn takes 3-4 attempts to connect but once connected then doesnt sign out

[maz9009]

Type 192.169.1.1 in your web browser. Type "admin" as user name & password. Hover your mouse cursor at WAN under Advanced. Select fourth option that should be your PTCL connection. It should be below connection scan option.

Take a snapshot of that page or remember the VCI and other options. Also you should know your connection password and user name supplied by PTCL. If you don't know the password than call and ask them.

Now plug in your Aztech Modem. Clear browser cache so that Aztech configuration page will load instead of Shiro. Go under WAN>New connection (same page from where you copied the settings for Shiro modem). Plz note that Shiro and Aztech both have similar Chipset. So configuration options will be similar. Copy the VCI settings, User name & Password to the relevant fields. After you are done with that. Click on Submit and save settings. After that restart the modem. Enjoy PTCL on Aztech modem.

Edit: Above method works 100%. I have tried it personally.

[BuNkLy]

thanks alot man.....im 2 on PTCL with Aztech

[m0d]

Originally Posted by maz9009

Type 192.169.1.1 in your web browser. Type "admin" as user name & password. Hover your mouse cursor at WAN under Advanced. Select fourth option that should be your PTCL connection. It should be below connection scan option.

Take a snapshot of that page or remember the VCI and other options. Also you should know your connection password and user name supplied by PTCL. If you don't know the password than call and ask them.

Now plug in your Aztech Modem. Clear browser cache so that Aztech configuration page will load instead of Shiro. Go under WAN>New connection (same page from where you copied the settings for Shiro modem). Plz note that Shiro and Aztech both have similar Chipset. So configuration options will be similar. Copy the VCI settings, User name & Password to the relevant fields. After you are done with that. Click on Submit and save settings. After that restart the modem. Enjoy PTCL on Aztech modem.

Edit: Above method works 100%. I have tried it personally.

any similiar procedure for ZXDSL 831 series modem ptcl users?

[Zappo]

Ptcl's Vpi=0
Vci=103

put it with ur login password, you can use any dsl modem on ptcl dsl.

[maz9009]

Originally Posted by Zappo

Ptcl's Vpi=0
Vci=103

put it with ur login password, you can use any dsl modem on ptcl dsl.

Yes...
AFAIK PTCL has different VCI settings for their ONU (fiber optic) DSL connections.

It's VPI is 8
and VCI is 81

Broadband Pakistan (DSL)

[Zappo]

my bad i didnt know he had a fibre optic line :/

[maz9009]

Originally Posted by Zappo

my bad i didnt know he had a fibre optic line :/

I didn't know either. I mentioned it just in case...

[Zappo]

what is the difference between copper dsl and onu dsl. Speed difference?. And what does onu means?

[Roadhog]

If i'm not wrong... ONU = Optical Network Unit.

Basically the old network we had for PTCL was all copper. from exchanges to those cabinets to your home all copper wires

New exchanges they are deploying now are fiber optic, from their end to ONU (that Box like thing deployed near by) to which all the copper wires lead to. Basically you do get a copper line, but its for only a short distance, rest of the distance is covered on fiber.




again I can be wrong...

[BuNkLy]

Originally Posted by Zappo

what is the difference between copper dsl and onu dsl. Speed difference?. And what does onu means?

from my experience and of few of my friends', ONU has about 10-15k download speed advantage over copper, but that mayb be different for every1 cz of their distances from their exchange, but that too may only be the case with copper lines.

[Meta]

ur right bunkly plus also add latency...
